WASHINGTON, DC, April 22, 2021 — At the Leaders Summit on Climate hosted by President Biden, the U.S. government pledged to help countries achieve their climate ambitions through expanding access to clean cooking.

“Providing clean energy to households is critical to achieving global climate and sustainable development goals,” said Helena Molin Valdés, Head of the Climate and Clean Air Coalition Secretariat. “Smoke from fireplaces, cook stoves, and lighting is responsible for more than half of human-made black carbon emissions and millions of premature deaths from household air pollution. The Climate and Clean Air Coalition partners welcome the U.S. government’s re-engagement in the issue and look forward to cooperating to put in place solutions that improve lives and protect the planet.”

The United Nations Foundation’s Clean Cooking Alliance

Would it be helpful to add climate metrics to the health-based ISO 19867? Currently, Scoring Tier 5 for emissions of PM2.5 and CO means that safety is assured in average households. As the score decreases from Tier 5 to Tier 0 the estimated amounts of ill health from breathing smoke and gas increase.

During ISO 19867 testing under an emissions hood, the fuel use, thermal efficiency and emissions of CO2, CO, and PM2.5 are measured and the data is used to determine a ranking on the voluntary tiers of performance. ARC multiplies lab data by a factor of three to estimate in field emissions. Usually in cook stoves, the CO2 has by far the largest effect on climate change. However, PM (black to white in color), CO, methane (CH4), non-methane hydrocarbons (NMHC), and nitrous oxide (N2O) also have varying amounts of climate forcing potentials. Currently, CO2, PM2.5, and CO are measured as a part of ISO 19867. ARC also determines the amount of black carbon in every test (using a filter) of PM2.5. Adding methane and non-methane hydrocarbons to the measured gases is not difficult. In fact, Sam is working on adding them to the LEMS right now.

The effects of inhaling particulate matter have been widely studied in humans and animals. They include asthma, cardiovascular disease, and premature death. Particles can also have an extremely strong effect on the atmosphere by absorbing and/or scattering the sun’s incoming radiation, depending on their color. The black particles have an approximate warming potential by weight of 680 times that of CO2 (Roden and Bond, 2006; Bond and Sun, 2005).

Total global warming impact, grams CO2 equivalent on a 100-year time-frame, per liter of water boiled and simmered for 30 minutes, normalized for starting temperature and fuel moisture content. Inclusive of CO2 and all PICs.

When we studied the global warming impact of five cook stoves burning biomass, CO2 was shown to be the major component, as seen above. At the time (2008), estimates of the various warming potentials were:

CO2….1  (IPCC, 2007)
CO….1.9  (IPCC, 2007)
CH4….25  (IPCC, 2007)
NMHC….12  (Edwards and Smith, 2002)
N2O….298  (IPCC, 2007)
PM – Black….680  (Roden and Bond, 2006; Bond and Sun, 2005)
PM – White….-50 (Estimate – Bond, 2007)

Warming potential, 100-year, CO2 equivalents

  • When biomass is harvested sustainably, the CO2 emissions from biomass-burning are considered to be greenhouse-neutral.
  • Although N2O is a strong climate-forcing constituent, emissions from the wood- and charcoal-burning stoves were very low, contributing less than 1% to the overall warming potentials.
  • The data suggests that there are biomass stoves that can be designed to (1) reduce the fuel used to cook, (2) reduce health-damaging emissions and (3) address climate change. The considerable differences in climate-changing emissions from the stoves in this study should be noted. Large-scale use of cleaner burning stoves might well reduce global warming effects, especially when the biomass is harvested in a “carbon neutral” manner. (N. MacCarty, D. Ogle, D. Still, T. Bond, C. Roden, Energy for Sustainable Development, 2008)

In our newsletter “Making It Real,” we described how feedback from the field in Rwanda suggested that the Jet-Flame’s power cord would last longer if the whole device was inserted from the side of the combustion chamber. (It was originally designed to go through the door, with the sticks placed on top.) So of course we ran some tests, and discovered more benefits.

Is the Jet-Flame, when inserted into the combustion chamber from the side of the CQC stove, as effective in reducing emissions as when it enters through the fuel door?

Yes, performance seems to have even improved a bit. After testing the Jet-Flame with side entry, it seems that it’s better to get the hot metal out from under the parts of the fuel that you don’t want to heat up. To burn cleanly, natural draft Rockets like to burn something like 8cm of the end of the sticks. Instead of laying the entire length of the sticks on the heated metal of the Jet-Flame, the side entry only exposes a limited amount of the sticks to high temperatures.

As seen in the photo, the sticks are now supported by a white homemade high mass brick and only the tips are exposed to Jet-Flame heat well inside the stove. It’s nice how a suggested change from Jean Marie Kayonga in Rwanda ends up having some unexpected benefit, not just better protecting the cord. Thanks again, Jean Marie! www.Jet-Flame.com

The time to boil, thermal efficiency, temperature in the combustion chamber, CO, and PM were improved with side entry while firepower rose. Excess air fell from 3.38 times stoichiometric to 2.57. I liked operating the stove because the sticks seemed to burn more at their tips as Dr. Winiarski described in the Rocket Design Principles. See: http://bioenergylists.org/stovesdoc/Still/Rocket%20Stove/Principles.html

When I went to UC Berkeley, studying psychology as an undergrad, lots of people made fun of Freud, Jung, and Adler who wrote (a lot) about divergent theories of what makes people tick. UCB liked to think of itself as a scientific institution, and facts are proven by statistical validity. Why should we believe speculation from the dear departed? I eventually agreed and I was intrigued by the big question: How do we know the truth?

The paradigm that captured my thinking was the BLACK BOX. In black box theory facts are like an elephant in a box. Scientists poke sticks into small holes in the box and one stick hits a toenail. A scientist exclaims, “Why, what is in the box is hard and slippery!” Other sticks hit the softer belly or the trunk, resulting in very different observations. Hopefully, after many experiments an accurate description of the elephant can emerge. (Although, what the elephant is thinking may well remain private.)

I was really excited by statistics!

If you’re trying to know the effectiveness of something, calculating the statistical significance can help. It gives you a measured amount of confidence in the hypothetical conclusion. At UCB we did experiments and 95% confidence was the minimum that students had to achieve to get an “A.” To achieve 95%, the sample size and the size of the effect had to be big enough.

Here’s the application to stoves

When we try to use found wood sticks from the forest in our experiments, one stick, for example, has two inches of bark on it. Another stick has three inches of bark and the two sticks make very different amounts of smoke. So, the variable of using sticks that emit different amounts of smoke makes it more difficult to know the truth: Did changing the air/fuel ratio, for example, result in the stove making less smoke? Using wood with no bark, we can achieve confidence in five to seven tests. We have to do a lot more tests when the fuel has added variables.

When trying to understand heat transfer or combustion efficiency in the lab (not what happens in the field) limiting variables has a great appeal to lazy researchers like me at ARC. So, we do not design stoves in the lab!

We realized quite a long time ago that we could only investigate heat transfer and combustion efficiency in the lab, and then with great relief go to an amazing place, work with wonderful people in a new culture, eat incredible meals, etc. in order to help a local team evolve a stove using found everything (and testing/statistics).

CQC stove with swinging door
CQC stove with swinging door
A door was added to the CQC stove to block some of the air entering the combustion chamber.

Last week we shared some thoughts about the importance of gathering detailed data and making direct observations when testing stoves. Here’s a question we recently considered.

Did a partial cover over the sticks entering the combustion chamber help reduce emissions in the CQC stove with Jet-Flame?

No, not in this preliminary test series, although lots of interesting things happened! Placing a swinging door over the fuel opening into the combustion chamber has often occurred to Rocket stove designers and it appears now and then in stoves. Dr. Winiarski liked the swinging door.  The thought is to get the excess air down by reducing the amount of air coming into the combustion chamber through the door. With sufficient but less excess air, the temperatures needed for cleaner combustion should rise.

Excess air did go down when a metal cover was near to touching the tops of the sticks in our experiments. It fell from an average of 2.91 times stoichiometric to 2.54. The average temperature in the combustion chamber did rise as a result, from 557°C to 596°C. The partial cover was doing its job. Firepower went up (4359 watts up from 4012 watts) and that might have helped with heat transfer efficiency. However, in this particular case, the thermal efficiency was unchanged (36% covered and 37% uncovered).

The positive changes in excess air and temperature also did not affect the emissions. PM2.5 (56mg/MJ-d covered and 55mg/MJ-d uncovered) and CO (2.63g/MJ-d covered and 2.72 g/MJ-d uncovered) were not changed enough to show a difference. Of course, using a Jet-Flame that is introducing lots of changes into the combustion chamber, including more excess air, probably makes this an unusual set of circumstances.

The swinging door may be great in a natural draft Rocket stove and as usual, Dr. Winiarski was right. It didn’t seem to be needed in this scenario. That’s OK with me, because the cover obscured the visual clues that help to tend a fire, and make tending more fun. I felt like I was flying a plane through the fog and was glad to land.

Kirk Harris tests his newest TLUD design under the Laboratory Emissions Monitoring System (LEMS) hood.

Having an emissions hood allows ARC to make more detailed observations. We try to do one ISO 19867 test every day, establishing an in-house culture of data driven inquiry. Now, having a hood isn’t necessary for creating amazing stoves. Larry Winiarski, Tom Reed, Paul Anderson, Kirk Harris, and many other people have spent happy hours tweaking prototypes that then worked better and better. But when you get to the point where it’s hard to see the smoke, visual inspection doesn’t work as well. In the modern world, health requirements are violated by fairly invisible amounts of PM2.5. Of course, the same thing goes for CO which is odorless and invisible.

That’s why we offer free access to serious stove developers. Kirk Harris recently visited the lab to tune up his latest TLUD. We have a nice, warm cabin for him and daily access to one of our two emissions hoods. The cafeteria is open and Kirk brings food to prepare. If we are lucky, we hear him playing his flute. Dale Andreatta makes an almost annual visit and then likely climbs some mountain and goes somewhere to watch trains.

Steps of scientific inquiry

  • Complete background research into the topic
  • Observe the natural process
  • Make a hypothesis based on the observations and test it

We’ve recently added 4 oxygen sensors and 4 temperature probes to the data generated every second for greater depth of detail. Detailed observations help to see if one set of information had an effect on another.  For example, when temperatures rose at 3” up from the floor of the combustion chamber did CO or PM2.5 change at the same time? Was a significant effect on CO or PM2.5 seen above a certain temperature? What happened with the temperature probe data taken at 4” up from the floor? And more and more. The process of learning is data driven which makes a black box theorist happy.

In so many ways, the detailed observation of what is happening in a biomass stove is in its infancy. Establishing a culture of daily data generation at our lab (3 hours) is getting us closer to having “observed the natural process.” And, it’s Christmas fairly frequently when a statistically significant relationship is observed.

The high mass CQC stove with Jet-Flame inserted from the side.
The Jet-Flame in the CQC high mass brick Rocket stove

I ask for help when moving the CQC stove. We built it on a piece of plywood and two folks can, with care, move it around the lab but it is heavy. The sand/clay/cement bricks are dense at 1.4 grams per cubic centimeter after being baked many times in the stove. Dr. Winiarski advised that, when possible, Rocket stoves should float in water at less than 1 gram per cubic centimeter.

For a long time, people have added sawdust and other lightweight materials into earthen mixtures to try to lighten up stoves. I ended up at Shengzhou Stove Manufacturer (SSM) in China because for hundreds of years ceramicists had manufactured (and sold in Africa since 1407) durable earthen stoves that weighed around 0.7 grams per cubic centimeter. Their amazing clay floats when dug out of the ground! It is full of diatomaceous earth. The Shens own a 100 year supply of clay in two mines next to the factory.

Why go to all of this trouble to lighten stoves?

The heat from the fire is diverted into the mass of the stove body and less heat is available to cook food. It is harder to start a hot, intense fire in a high mass combustion chamber. In a natural draft stove, this can be disadvantageous. The open fire has other problems but, out of the wind, the hot gases from the flames directly contact the pot and it’s common for open fires to have higher thermal efficiencies compared to high mass stoves, including Rocket stoves. Lightening the bricks helps to address this difficulty. Heat is still diverted into the stove body, but less. Well insulated, mostly metal, Rocket stoves successfully avoid most of these losses.

Indigenous cooks, experts at using fire, often use grasses and twigs to start a hot, fast fire in a high mass stove. You need to pour the BTUs into the stove to quickly prepare food. Speed to cook is almost always the first priority when talking to cooks around the world. When the SSM Jet-Flame is added to the high mass stove, the mini blast furnace immediately starts a hot, over 1,000°C fire that delivers relatively hot gases into the channel gap around the pot created by the pot skirt. (The CQC skirt creates a 5mm channel gap that is 7cm high.)

The Jet-Flame creates a surprising result

The thermal efficiency in the first CQC/Jet-Flame test (see below) was 33%. The 5 liters of water boiled in 12.5 minutes. After the first 12.5 minutes of heating, the over 1,000°C fire started to heat up the mass and the water boiled more quickly in 10.2 minutes at 38% thermal efficiency. Three more short, but intense, heating phases resulted in the thermal efficiency incrementally rising to 41%, 42%, and 45%. The progressively hotter gases scraping against the sides and bottom of the pot in the small channel gap were more and more successful at transferring heat through the metal walls of the pot into the water.

When thermal efficiencies are in the 40% to 45% range, the performance of the high mass stove is similar to low mass, insulated Rocket stoves. This similarity was completely unexpected at ARC.

Results of five tests of the CQC Stove with Jet-Flame.
A woman sits next to two rocket stoves.
A woman sits next to two rocket stoves.
Firewood is stored between a pair of CQC’s TLC Rocket Stoves.

C-Quest Capital recently announced a collaboration with Macquarie Group Ltd., a financial services company with A$550 billion in assets under management and 16,000 employees in 35 countries. The two firms will fund and deploy efficient cook stoves with pot skirts to one million rural households across Malawi, Zambia and Tanzania. CQC’s preferred rural stoves project standard is two stoves per household to decrease user fallback on three-stone fires.

USAID in-field testing in Africa showed that Rocket stoves with pot skirts reduced smoke emissions by 40% due to the use of less wood while cooking. Addressing health by increasing the air exchange rate in the kitchen and home is a fundamental component of this project. This is done by strategic placement of windows and doors, and promoting half-wall kitchens or well-protected external cooking spaces. A minimum of one visit per year by trained staff to each household to help repair, maintain, and ensure good use of the Rocket stoves is also essential to elevating adoption rates in the targeted areas.

Over the next decade, this investment will deliver over 40 million high quality carbon credits with verified Sustainable Development Contributions to the Voluntary Carbon Market. It is the first leg of a three-pronged program to transform the lives of low-income communities across Sub-Saharan Africa at scale. Ken Newcombe, CEO of CQC, comments, “Our hope is to include something like 100,000 Jet-Flames, assembled by Ener-G-Africa in Lilongwe, Malawi, in the project. Field tests have indicated that the Jet-Flame dramatically reduces PM2.5 emissions and exposure to cooks and their families, further protecting health. If the deployment doesn’t get to 100,000 sold by end of next year it’s not because of the demand – it’s because we couldn’t get the working capital and distribution channels to get the product to the market. Of course, we are exploring all possibilities.”

Sam Bentson and a Winiarski designed down-feed downdraft Rocket stove with added cooling fins.

We used to have problems with the upper portion of the sticks catching fire in Dr. Winiarski’s down-feed downdraft Rocket stoves. The draft had to be strong, and the sticks at the right moisture content and size/weight to burn up completely without any smoke back drafting up into the room. The vertical metal feed tube got too hot and could catch the top part of the sticks on fire, overcoming the draft moving into the stove. (Usually something like 3 MPH.)

When Sam Bentson and Karl Walter were making a 20 watt thermoelectric generator (TEG) for the EPA SBIR supported Integrated Stove project we had the same problem, until Sam added aluminum cooling fins to the top of the vertical feed tube, as seen above. The team had previously designed and built the cooling fins unit that Sam is holding in the photo to cool the cold side of the TEG. I was amazed how well cooling fins work!

But then I remembered how small the radiators are in automobiles with huge horse powers. I saw that Sam and Karl had added a fan to their radiator to make sure it could dissipate the 1.5 kilowatts running through the hot side of the TEG. Adding fins to parts of a stove that could use more dissipation of heat brings to mind several possible applications: the heat exchanger cylinder in the photo, a chimney that has high exit temperatures, or the outside of a metal combustion chamber to preserve the metal. But I would not use fins where they can get dirty! They don’t work, for example, on the bottom of a cooking pot where soot quickly fills the space between the fins. (I didn’t think of this before we tried it.)

Manufacturing pot skirts

In 2013, C-Quest Capital (CQC) began distributing and installing the TLC Rocket Stove (TLCRS), a high-efficiency, long-life metal and brick improved cookstove, to the rural poor of Malawi. Early learning has resulting in many upgrades to the stove to improve sustained use and a long life. Over the past two years, CQC has installed the TLCRS in 450,000 Malawian households. Beginning in January 2020, Ener-G-Africa (EGA), a Malawian entity formed by CQC and Malawian entrepreneurs, began manufacturing all the metal stove parts for CQC’s sub-Saharan Africa TLCRS program and has since produced more than 300,000 sets of parts.

Interior view of EGA Stove factory in Lilongwe, Malawi
Stove Kits ready to ship at Ener-G-Africa’s factory in Lilongwe, Malawi

More recently, in February 2021, CQC placed irrevocable orders for the first 10,000 Jet-Flames from Shengzhou Stove Manufacturer in China, marking the first large scale commercial commitment to Jet-Flame distribution in the world. With CQC’s funding, EGA’s factory in Lilongwe is currently building the second solar panel assembly plant in sub-Saharan Africa and will begin manufacturing the solar panels, and eventually the batteries, needed for the Jet-Flame Kit.  CQC is hoping the superior cost and cooking amenity provided by the Jet-Flame will make serious inroads to the charcoal user market.

Through the growing partnership between CQC and EGA, the TLCRS will be installed on a two stove per household basis in three million households across eight sub-Saharan African countries in the next four years. Together, CQC and EGA are setting a new standard for cookstove projects in rural Africa.

Manufacturing pot skirts
Welded pot supports
Parts ready for packing
Manufacturing area at Ener-G-Africa’s factory in Malawi
CQC stove set up for testing under the LEMS hood

ARC is investigating how to optimize the performance of the SSM Jet-Flame in the CQC earthen brick stove. Forty six thirty-minute ISO 19867 Water Heating Tests were completed under the LEMS hood at seven fan speeds. Two 4 cm x 4 cm douglas fir sticks were burned side by side. Five liters of water in a seven liter pot were heated, and the CQC pot skirt was used in all tests.

Results

Tier 4 ISO Voluntary Performance Targets:

  • Thermal Efficiency           40% to 49%
  • CO                                     <4.4g/MJd
  • PM2.5                               <62mg/MJd

Time to boil: The time to boil decreased with an increase in fan speed.

Thermal efficiency: The thermal efficiency stayed close to 35% in most cases and was higher at 3 and 8 volts (around 40%).

Firepower: The firepower rose to 6.8kW at 8 volts, starting at 2.6 kW at 2 volts.

Emissions of Carbon monoxide: Generally emissions decreased with increasing fan speed.

Emissions of PM2.5: 7 and 8 volts scored the best, at half of the result of 5 volts.

Combustion chamber temperatures: The mid combustion chamber temperatures rose with increases in fan speed from 382C to 730C.

Excess air:  Lambda fell as voltage increased from 4.1 to 1.9.

We recommend that the project do enough field testing to determine what settings are preferable to local cooks, remembering that higher voltages consume more power. In this way, the Jet-Flame/CQC stove can be tailored to regional cooking, keeping in mind the power output and use patterns of the CQC photovoltaic solar system.

Here’s what the flame looks like when varying the voltage:
